This information is provided for reference purposes only . To find out which pump is best for your application, please fill out our
MOTOR ENCLOSURE
TEFC “Totally Enclosed, Fan Cooled":
Totally enclosed motors are suitable for use in humid environments. The motor is dust tight and has a moderate water seal as well.
Washdown:
Designed to withstand high pressure wash-downs or other high humidity or wet environments. This does not allow for the motor to be submerged.
Specifications:
Pump wetted materials: 316L Stainless Steel
Connections: 2" X 1 1/2" Tri-Clamp
Impeller size: 6"
Mechanical seal: Carbon (Standard)
Seal type: DG seal
Elastomers: Buna (Standard), FKM and EPDM (Optional)
|
DO YOU HAVE THE MOTOR?
Please contact us for price |
C-216 Head pump (Without motor) Ready to install in a Nema C-face motor WHAT NEMA FRAME DO YOU NEED? For more Info. please call 281-288-0286 |
Motors: 3 - 10 HP
| 3-Phase motor (Washdown) |
|
* 3-Phase, 60Hz, inverter rated 10:1 * NEMA frame: 3 HP NEMA 145TC FRAME 5 HP NEMA 184TC FRAME 7.5 HP NEMA 213TC FRAME |
